NM400/NM450/NM500 Equivalents: HARDOX 400/450/500 Class Wear Plate
NM400, NM450 and NM500 are the Baosteel equivalents of HARDOX 400, HARDOX 450 and HARDOX 500, matching them in hardness class, mechanical properties and wear resistance at a significantly lower price per ton. We supply them with original Baosteel mill test certificates and optional third-party inspection. See our Baosteel steel supplier page for the full grade range, or compare wear plate brands in depth in AR500 vs HARDOX 500 vs NM500.
3 Reasons to Import Wear Plate from Baohui
1 High-Quality Steel that Meet International Standards
With the continuous upgrade of China's steel industry, the domestic production of abrasion-resistant steel can now meet, and even surpass, international standards. Baohui Steel Limited ,as the first-level dealer of Baosteel, a leader in China's steel industry, has a large inventory of high quality abrasion-resistant steel plates for the international market.
Baosteel Standard NM400 vs. International Standard AR400
Although there is a difference in the naming of the Baosteel standard NM400 and international standard AR400, both materials undergo strict quality control regarding chemical composition, mechanical properties, and wear resistance to ensure they meet the demands of various industrial applications. Baosteel's production of NM400 abrasion-resistant steel, with its excellent balance of hardness and toughness, is widely used in mining, construction, and agricultural machinery, among other fields.
| Steel Grade | SSAB | Thyssenkrupp | JFE | DILLIDUR | Ruukki |
|---|---|---|---|---|---|
| NM400 | HARDOX400 | XAR400 | EH400 | 400V | Raex400 |
| NM450 | HARDOX450 | XAR450 | - | 450V | Raex450 |
| NM500 | HARDOX500 | XAR500 | EH500 | 500V | Raex500 |
NM400/NM450/NM500 vs Hardox 400/450/500: Guaranteed Specs Side by Side
| Baosteel grade | SSAB equivalent | NM hardness guarantee | Hardox hardness guarantee | NM thickness range |
|---|---|---|---|---|
| NM400 | Hardox 400 | ≥370 HBW | 370–430 HBW | ≈1.5–25 mm — incl. the 1.5 mm class unique to Baosteel; heavier gauges on request |
| NM450 | Hardox 450 | 420–480 HBW | 425–475 HBW (plate ≤80 mm) | |
| NM500 | Hardox 500 | 500 HBW class — delivered 470–540 HBW | 470–530 HBW (plate ≤32 mm) |
Guarantees are one thing — delivered metal is another. Two real Baosteel inspection certificates from shipments to Baohui Steel: NM450 10 mm measured 452 HBW average, 1,250 MPa yield and 52 J at −20 °C (cert. BGSAI2402270700100); NM500 12 mm measured 517 HBW average, 1,410 MPa yield and 62 J at −20 °C (cert. BGBWI2504240235400). Read the full head-to-head comparisons with prices: NM400 vs Hardox 400, NM450 vs Hardox 450 and NM500 vs Hardox 500 — or the three-way AR500 vs Hardox 500 vs NM500.
Indicative FOB Shanghai for the NM series: 720–930 USD/MT depending on grade, thickness and volume — every shipment with original Baosteel mill test certificates and ISO 14025-verified EPDs. Request a firm quote.
2 Competitive Steel Distributor
Another significant advantage of our wear plate is its competitive pricing. Benefiting from mature production technology and economies of scale, Baosteel can produce high-quality abrasion-resistant steel at a lower cost, giving abrasion-resistant steel a price advantage in the international market. This combination of cost-effectiveness offers global buyers an excellent value proposition.
BaohuiSteelLimited - A Premier Partner of Baosteel
Shanghai Baohui Steel Limited, as a premier partner of Baosteel, proudly announces that we maintain a stock of over 10,000 tons of abrasion-resistant steel, covering the full series of NM400, NM450, and NM500 products. In addition, we also possess the market-scarce NM600 series of abrasion-resistant steel, meeting the needs of high-end applications.
Our inventory management strategy and supply chain optimization ensure the rapid delivery and high-quality standards of our products. Whether it is standard wear-resistant steel plates or special specification custom demands, Baohui can provide a one-stop solution.
3 Sufficient Stock and Rapid Logistics
We typically has ample stock resources and can quickly respond to overseas order demands, achieving rapid shipment. This rapid logistics capability ensures that abrasion-resistant steel materials can reach customers on time, reducing the waiting time for engineering projects and accelerating construction progress.
Typical HS Code for wear resistant plate：722540
Mechanical Property
| Grade | Yield Strength MPa | Brinell hardness HBW | Elongation A | Impact Strength Charpy V 20 J |
|---|---|---|---|---|
| NM400 | 1200 | ≥370 | 9 | 17 |
| NM450 | 1250 | ≥420 | 7 | 17 |
| NM500 | 1450 | ≥470 | 5 | - |
Chemical Composition
| Grade | C | Si | Mn | P | S | Al | Cr | Ti | B | CEV |
|---|---|---|---|---|---|---|---|---|---|---|
| NM400 | 0.3 | 0.7 | 1.6 | 0.025 | 0.01 | 0.01 | 1 | 0.05 | 0.005 | 0.46 |
| NM450 | 0.35 | 0.7 | 1.7 | 0.025 | 0.01 | 0.01 | 1 | 0.05 | 0.005 | 0.52 |
| NM500 | 0.38 | 0.7 | 1.7 | 0.02 | 0.01 | 0.01 | 1.1 | 0.05 | 0.005 | 0.55 |
Wear-Resistant Steel: Investing in Time, Not Just Steel Plate
In industries ranging from excavator buckets and mining chutes to cement mill liners, the most persistent and costly issue is rapid wear. Ordinary steel plates lack sufficient hardness. When confronted with sand, ore, and aggregate, they are quickly worn through.
Frequent plate replacement leads to rising hidden costs from labor and downtime. A seemingly inexpensive steel plate can result in costly production line stoppages. What truly impacts profitability is not the unit price of the steel plate, but "service life + downtime."
The Core Logic of Wear-Resistant Steel: Purchasing Time, Not Plate
Wear-resistant steel plates (such as NM400/NM500/NM600) are significant not just for their "high hardness," but for their ability to:
- Extend Service Life: Offer a 2-5 times longer lifespan compared to ordinary steel plates
- Reduce Downtime: Less frequent plate replacements mean less machine idle time and maintained production capacity.
- Ultimately Cost-Effective: A single wear-resistant steel plate can outperform several ordinary plates, leading to lower comprehensive costs
In summary, wear-resistant steel doesn't add cost; it saves money in ways that aren't immediately visible.
Industries That Must Use Wear-Resistant Steel
Wear plate has a place in hundreds of industries and applications.These applications are often found in:
Construction equipment. Construction equipment, including structural beams, bulldozers, compactors, and more, can benefit from the use of AR steel as most of this equipment will come into contact with highly abrasive media.
Mining equipment. All of the tools used in mining and excavating need to be abrasion, wear, and impact resistant. Heavy and highly abrasive material often comes into contact with the tooling, parts, and machinery used in this industry, so NM steel isn’t just beneficial. It’s a must.
Agricultural tooling. Most common tools and equipment you find in the agricultural industry are lined or made of abrasion-resistant steel. With constant outdoor use, this equipment directly benefits from the wear resistance NM steel provides.
The commonality in these areas is severe wear and high downtime costs. Any stoppage translates to decreased output, delayed orders, and wasted labor costs.
From "Buying Steel" to "Buying Solutions"
Many manufacturers remain stuck in a "unit price comparison" mindset, opting for the cheapest option. However, astute purchasers are shifting their focus:
- Compare not unit price, but service life.
- Consider not just the immediate cost, but the total lifecycle cost.
- Look beyond the steel plate itself to its potential for improving equipment utilization rates.
This is why an increasing number of manufacturers are proactively engaging with wear-resistant steel plate suppliers instead of solely pursuing low-cost ordinary plates
Wear-Resistant Steel is a Future Necessity
In the competitive landscape of machinery manufacturing and equipment maintenance, those who can ensure longer service life and less downtime will achieve higher profitability and gain customer trust. Upgrading to wear-resistant steel isn't just about better material; it's an upgrade in competitive strength for your business.
Looking Ahead: The future of wear-resistant steel involves smarter, more integrated solutions. Trends like nanocrystalline strengthening and gradient microstructure control will further enhance hardness while improving toughness and weldability. The integration of Industrial IoT (IIoT) and condition monitoring systems will enable wear-resistant components to predict their own remaining life, facilitating a shift from reactive replacement to proactive maintenance. Embracing these advancements with wear-resistant steel is a strategic move towards greater efficiency and profitability.
